Part Names and Functions
To ensure safe operation, please observe the following
precautions :
– Do not bend, drop the remote control or expose the remote
control to moisture or heat.
– For cleaning, use soft dry cloth. Do not apply benzene,
thinner, splay or any chemical material.
⑤
③
⑨
⑬
④
⑭
⑫
① ON/STAND-BY button
Turn the projector on or off. (pp.19, 20)
② VIDEO button
Select VIDEO input source. (pp.25, 36)
③ COMPUTER button
Select COMPUTER input source. (pp25, 27, 37)
④ MENU button
Open or close the On-Screen Menu. (p21)
⑩
⑦ D.ZOOM ▲▼ buttons
Zoom in and out the images. (pp.25, 35)
⑭ AUTO PC button
Automatically adjust the computer image to its optimum setting.
(pp.25, 29)
⑬ IMAGE button
Select the image mode. (pp.26, 32, 39)
⑧ FREEZE button
Freeze the picture. (p25)
⑪
MUTE button
Mute the sound. (p 24)
⑫
P-TIMER button
Operate the P-timer function. (p26)
⑨
NO SHOW button
Temporarily turn off the image on the screen. (p26)
⑮
KEYSTONE button
Correct the keystone distortion. (pp.23, 43)
⑤ Point ▲▼◄►( VOLUME
+ / –
)
buttons
– Select an item or adjust the value in the On-Screen Menu. (p21)
– Pan the image in Digital zoom + mode. (p35)
– Adjust the volume level. (Point
◄►buttons) (p24)
⑥ SELECT button
– Execute the selected item. (p21)
– Expand or compress the image in Digital zoom mode. (p35)
①②
⑥
⑦
⑧
⑮
⑪
⑩ LAMP CONTROL button
Select the lamp mode. (pp.25, 49)
Remote Control
