Parts List
# Part Number Description Qty
1
PMJ22H-02-00 Beam 1
2
GB/T 5782-2000 Bolt M12×75(12.9) 1
3
PMJ22J-04-00 Wedge Slide 1
4
GB/T 95-2000 Washer 12 7
5
GB/T 889.1-2000 Lock Nut M12 8
6
PMJ22G-51 Filter Housing "IN" Connection 1
7
PMJ22J-12 Control Valve 1
8
PMJ22G-24 Valve Joiner 1
9
JB 982-1977 Combination Washer 14 4
10
PMJ22G-25 Valve Joiner 1
11
GB3452.1-92 "O" Ring 14×2.65 1
12
PMJ22G-22 Front Cover Connector 1
13
PMJ22G-23 Bolt Connector 2
14
PMJ22G-49 Filter Housing "OUT" Connection 2
15
JB/T 8870－1999 Clamp d25 2
16
PMJ22G-16 Hydraulic Hose(Valve-Cylinder) 1
17
PMJ22J-08-00 Cylinder 1
18
GB/T 5783-2000 Bolt M8×20 8
19
GB/T 93-1987 Lock Washer 8 20
20
GB/T 95-2000 Washer 8 20
21
PMJ22J-03 Cylinder Fixing Plate 2
22
PMJ22J-15 Pin 1
23
PMJ22G-30 R Pin 2
24
PMJ22G-15 Hydraulic Hose(Valve-Oil Tank) 1
25
GB/T 95-2000 Washer 10 8
26
PMJ22J-06 Base Tube 1
27
PMJ22J-01-00 Base Connector 1
28
PMJ22J-10 Pin 1
29
PMJ22G-40 2" Coupler 1
30
GB/T 5782-2000 Bolt M12×80 2
31
PMJ22J-07-00 Front Support Leg 1
32
PMJ22G-41 Safety Chain With Hook 2
33
GB/T 97.2-1985 Washer 12 4
34
GB/T 5782-2000 Bolt M12×90 1
35
GB/T 5782-2000 Bolt M12x65 2
36
PMJ22J-18 Hydraulic Hose(Valve-Pump) 1
37
GB/T 3452.1-92 "O" Ring 10×2.65 1
38
PMJ22G-21 Outlet Connector Of Pump 1
39
PMJ22J-14 Gear Pump 1
40
JB/T 8870－1999 Clamp d40 2
41
PMJ22G-17 Oil Pipe 1
42
GB/T 5783-2000 Bolt M8×30 4
43
GB/T 6170-2000 Nut M8 9
44
GB/T 77-2000 Screw M6×10 1
# Part Number Description Qty
45
PMJ22G-26 Gear Pump Connector 1
46
ASME B18.2.1 1996 Bolt 5/16"-24×1" 4
47
PMJ22G-29 Engine Bushing 1
48
YF168F-2-001 Engine 1
49
GB/T 1096-1979 Flat Key 1
50
PMJ22G-28 Engine Connector 1
51
PMJ22G-27 Gear Pump Stand 1
52
PMJ22G-32 Connector Cover 1
53
GB/T 845C-1985 Tapping Screw 4
54
GB/T 848-1985 Lock Washer 4 4
55
GB/T 859-1987 Washer 4 4
56
GB/T 1096-1979 Flat Key 1
57
GB/T 70.1-2000 Screw M5×20 6
58
GB/T 93-1987 Lock Washer 5 6
59
GB/T 95-1985 Washer 5 6
60
PMJ22G-07-00 Filter Fix Plate 1
61
PMJ22G-44 Filter 1
62
PMJ22G-19 Oil Plug 1
63
GB/T 3452.1-92 "O" Ring 80×3.55 1
64
GB/T 5782-2000 Bolt M8×45 4
65
PMJ22G-52 Auto Filter 1
66
PMJ22G-50 Auto Filter Base 1
67
PMJ22G-18 Screw NPT1" 1
68
GJY12-3 R Pin 1
69
GB/T 5782-2000 Bolt M12×85 2
70
PMJ22G-12 Hinge Pin 1
71
PMJ22J-11-00 Oil Tank 1
72
GB/T 91-2000 Cotter Pin 4×32 2
73
PMJ22J-05-01 Cased Seal 2
74
L44634 LYC DS Tapered Bearing 4
75
PMJ22J-05-03 Wheel 2
76
GB/T 9459-1988 Slotted Nut M20x1.5 2
77
PMJ22J-05-02 Axle Cap 2
78
PMJ22J-19 Plate 1
79
GB/T 859-1987 Washer 8 2
80
GB/T 818-2000 Bolt M8x12 2
81
PMJ22G-38 Big Tension Spring 1
82
GB/T 798-1988 Swing Bolt M8x28 1
83
GB 1160.2-89 Oil Scale 1
84
GB/T 93-1987 Lock washer 10 8
85
GB/T 5781-2000 Bolt M10x15 8
86
PMJ22F-01 Log Catcher 2
