Specifications
Rev 65521-20090226 19
Item Part Number Description Qty
107 ST168F-1101200-G Muffler 1
108 GB41-N-8 Nut M8 2
109 GB90-W-8 Washer ø8 2
110 GB93-LW-8 Lock Washer ø8 2
111 ST168F-1100001-G Muffler Packing 1
112 ST160F-1010002 Exhaust Bolt 2
113 ST168F-1080002-G Shroud 1
114
ST168F-1050007 First Ring Set 1
ST168F-1050006 Second Ring Set 1
ST168F-1050200 Oil Ring Set 1
115 ST168F-2-1050005 Piston 1
116 ST168F-1050004 Piston Pin Clip 2
117 ST168F-1050003 Piston Pin 1
118 ST168F-1050100 Connecting Rod Comp 1
119 ST160F-1030005-B Oil Filler Cap 1
120 ST160F-1070006 Fuel Filter 1
121 ST1P68F-1070006-F Clip 1
122 GB90-W-6 Washer ø6 6
123 GB93-LW-6 Lock Washer ø6 4
124 GB5789-FB6-35 Flange Bolt M6×35 1
125 GB5789-FB6-15 Flange Bolt M6×15 4
126 GB41-N-6 Nut M6 2
127 ST168F-1040014-A Oil Seal
2
