Yamaha DVD-S2700 Portable DVD Player User Manual



DISC OPERATION
16 En
Unless otherwise specified, all operations described here are
carried out using the supplied remote control.
If the inhibition icon ( or “Prohibit”) appears on the TV
screen when you press a button, the function for that button is
not available on the current disc or at the current time.
Depending on the DVD or Video CD disc, some operations
may operate differently or be restricted.
Do not push on the disc tray or put any objects other than discs
on the disc tray. Doing so may cause the disc unit to
malfunction.
1 Press on the front panel to open the disc tray.
2 Place a disc in the disc tray with the printed side
up.
3 Press again to close the disc tray.
After recognizing the disc, this unit starts to play
back automatically.
If you press PLAY (
3
) when the disc tray is
opened, the disc tray closes and playback starts
automatically.
Depending on the disc, the disc reading time may
exceed 30 seconds due to the complexity of the
directory/file configuration.
4 To stop playback, press STOP (
7
).
“RESUME” appears in the front panel display.
5 To resume playback, press PLAY (
3
).
The disc is played back from the last stopping
point.
y
As long as you do not eject a disc, you can resume playback even
if you turn off this unit.
6 To cancel resume mode, press STOP (
7
)
twice.
It may not be possible to play certain MP3/JPEG/DivX discs
due to the configuration and characteristics of the disc or the
recording conditions.
When you play a down mix prohibited disc, “NO DOWN
MIX” lights in the front panel display.
Pausing playback
1 During playback, press PAUSE (
8
).
Playback is paused and the sound is muted.
2 Press PAUSE (
8
) again to select the next
picture frame.
3 To resume normal playback, press PLAY (
3
).
Selecting a track/chapter
Press SKIP (l22 / 33 l) or use the numeric
buttons (0-9) to select a track/chapter number.
You can move to the top of the currently playing
track/chapter by pressing SKIP (
l22 ) once, and
move to the previous track/chapter by pressing
SKIP (l22 ) twice.
During repeat playback of a track/chapter, press
SKIP (l22 / 33 l) to replay the same track/
chapter.
DISC OPERATION
Notes
Basic operation
MULTI 2CH
RANDOM
GROUP PAGE
PROG
REPEAT
SETUP
PAUSE
STOP
SKIP
PLAY
A B
SLOW SEARCH
ENTERCLEAR
ON SCREENTOP MENU
STOP ( )
PAUSE ( )
SKIP ( / )
SLOW/SEARCH
( / )
PLAY ( )
Numeric
buttons (0-9)
Notes
