4. Press A-B/REC button again to save the selected channel.
Select a Preset Channel
1. Press the A-B/REC button, and the screen will display the 20 channel numbers.
2. Push the Menu Switch to the right (Next)
or to the left (Previous) to select the channel
number you want to use.
3. Press the PLAY-PAUSE/PWR ON
button to select the preset channel.
4. The desired stored favorite channel will appear on the OLED display.
Record an FM Channel
1. Select a desired channel.
2. Press and hold the A-B/REC
button for more than 2 seconds, and then the selected
channel will start being recorded. On the display, a recording FM file is generated and placed in
the folder name of [/FMIN.DIR/]. The recording file name sequence starts at [FM000001.WAV],
then [FM000002.WAV], and so forth.
3. Press the PLAY-PAUSE/PWR ON button to pause the recording, and press the
PLAY-PAUSE/PWR ON
button again to continue.
4. Press the A-B/REC
button again to stop the recording and the display will return to the
previous FM status screen.
Sample rate Channels 512MB 1GB
8 KHz
2 stereo
16 hrs 32 hrs
16 KHz
2 stereo
8 hrs 16 hrs
FM Record
32 KHz
2 stereo
4 hrs 8 hrs
The T.sonic™ 520 will not be able to support the maximum recording capacity described in the
above table if the memory space and/or the battery power level are smaller than shown on the
table.
