[ Controls ]
10
[ Controls ]
11
Car Dock Button Descriptions Continued
Button Action Live Environment Description
Playback
Environment Description
Media Dial
Turn
If listening to live broadcast,
tunes next channel
If in a list, menu, or prompt,
scrolls to next or previous item
If listening to playlist, no action
If in a list, menu, or prompt,
scrolls to next or previous item
Select
Press Selects highlighted items in lists, menus, or prompts
Hold
Allows you to Add/Move/Re-
move a preset
No Action
Playlists
Press
Allows you to browse the
playlists
Goes to the most recent playlist
menu screen and highlights the
currently selected song or show
If browsing playlists, moves up
one level in the playlist menu
structure
Hold No Action No Action
Back
Press
If listening, returns to previous channel or playlist
If in a list at the top level, exits and returns back to previous
content
If in a list not at the top level, moves up one level in the list
structure
Hold
Jumps to programmed traffic/weather or other channel
If a jump is pending, cancels jump
If in a list or in Setup, exits the list or Setup
Car Dock Button Descriptions Continued
Button Action Live Environment Description
Playback
Environment Description
Mode
Press
First push allows you to browse live channels according to the
current tuning mode
Second push cycles browse mode between Channel, Genre, and
Presets
Hold
Cycles between channel
name/artist/title when in
browse mode
No Action
Setup
Press
Displays the Setup menu
If in the Setup menus, moves up one level in the menu structure
Hold
First push and hold displays the frequency of the currently se-
lected FM preset for 10 seconds
Second and subsequent push within 10 seconds cycles through
the FM presets
Car Dock Connector Descriptions
Connector Description
FM OUT
FM output connection.
DC 5V
Connection for the Cigarette Lighter Adapter.
LINE OUT
Optional audio output for connection to the vehicle’s audio system. An
audio cable (not supplied) is required to utilize this connection.
ANT
Connection for the Magnetic Antenna.
