22
REC OUT socket
On the rear of your radio is for use with a tape recording/mini disc or
to allow connection to line input of a Hi-Fi system. The signal on the
Record out socket is unaffected by the volume control.
External 12V DC Input
If mains supply is not available, your radio may be powered by 12V
DC via the rear mounted 12V DC supply at 1A with the center pin of
the plug positive.
Headphone use
Headphone use with this radio should be fitted with a 3.5 mm
jack plug. Insert the headphones plug into the socket on the front
of the radio marked . When the headphones are plugged in,
the loudspeaker is automatically disconnected.
RESET the radio
If your radio fails to operate correctly or some digits on the display
are missing or incomplete, carry out the following procedure.
1. Switch off the radio.
2. With the aid of a suitable implement (the end of a paper clip),
press the RESET button located on the underside of your radio
for at least 2 seconds , this will reset the microprocessor,
clock time and clear all stations stored in the preset memory .
GB
