Troubleshooting/Reset button
If your radio fails to operate correctly or some digits
on the display are missing or incomplete, carry out
the following procedures.
1. Switch off the radio and remove the batteries.
2. With the aid of a suitable implement (the end of a
paper clip), press the RESET button located on
the underside for at least 2 seconds, this will
reset the microprocessor but still keep the clock
time and all stations stored in preset memory.
Specifications
Power requirements
DC 3V 200 mA center pin negative
Batteries 2 x UM-3 (AA size)
Circuit features
Output power: 100 mW (speaker)
Socket
Headphone socket 3.5 mm dia stereo
DC input socket 3.0 volts center pin negative
The company reserves the right to amend the
specification without notice.
