PORTABLE SOUND SYSTEM 150
2
Date of Purchase ____________________________________
Dealer’s Name ______________________________________
City _______________________________________________
State _____________________ Zip _____________________
Model # ____________________________________________
Serial # ___________________
FEATURES
TABLE OF CONTENTS
Congratulations on your choice of a portable sound system
— you have purchased one of the finest portable sound
systems on the market today. This unit was developed
using the expertise of professional sound engineers and
working musicians. You will find that your new NADY
AUDIO portable sound systems has superior performance
and greater flexibility than any other portable sound
systems in its price range. Please read this manual
carefully to get the most out of your new unit.
Thanks for selecting NADY AUDIO as your choice in
portable sound systems.
FEATURES ....................................................................... 2
WARNING ......................................................................... 3
INTALLATION................................................................... 4
1. INSPECTION.......................................................... 4
2. SETUP.................................................................... 4
FRONT PANEL CONTROLS & CONNECTIONS ............ 5
REAR PANEL CONTROLS & CONNECTIONS .............. 7
SPECIFICATIONS ............................................................ 7
• Convenient portable PA package with luggage-style handle and wheels for easy transport
• 5-Channel stereo 150W RMS powered mixer AMA™ (Automatic Maximum Amplitude) limiter speaker protection
• Stereo two-way speaker system with 10" woofer and piezoelectric tweeter horn, two speaker cables, and two folding
speaker stands
• Three combo XLR / 1/4" mic/line inputs and one XLR mic input, all with 15V phantom power, and two stereo source
inputs for CD, VCR, or DVD or other audio sources. All inputs with bass, treble, and reverb controls.
• Separate left and right master output 60mm linear fader level controls, choice of eight digital reverb and eight digital
delay effects, and five-band graphic equalizer with FLI™ (Feedback Locating Indicators).
• One Starpower™ dynamic microphone and 20 foot XLR microphone cable
• Storage compartments for microphones, cables and accessories
• Variable-speed fan
• Stereo RCA auxiliary outputs
