INSERTING AN iPod
Rotate the iPod Adjustment Knob 1 to
the number that corresponds to your
iPod (see chart on page 15). Press the
OPEN button
2 to open the
iPod compartment.
2
1
1
Locate the correct iPod universal dock
to use as shown on pages 13-14.
Insert the universal dock into the
compartment by making sure the two
tabs are facing front and slipping the
universal dock into place (as shown).
make sure two tabs are facing
front and slip dock into place
2
Insert the iPod into the compartment.
Gently push down so the connector on
the iPod slides onto the connector on
this unit. Close the compartment by
gently pushing the door back until both
sides click into place. If this unit is
turned on and in TUNER/LINE IN
mode, once the iPod is connected, it
will change to iPod mode
automatically. When the iPod is
connected to this unit, it will be in the
Pause mode.
3
To remove the iPod and universal dock
from this unit, make certain to remove
the iPod from the connector first. Then
remove the universal dock from
the compartment.
4
NOTES:
• CHARGING: When the iPod is inserted into the compartment and the unit is operating
on AC power, whether this unit is on or off, the iPod’s battery will charge until it is full.
•
CHANGING THE MODE: You can press the
MODE button repeatedly to select between
iPod/TUNER/LINE IN mode as desired. To turn off the unit, press and hold the
Power button.
