Memorex Mi3001 Portable Speaker User Manual



3
LOCATION OF CONTROLS
4
5
6
8
7
9
10
11
12
1
2
3
13
14
15
16
17
18
19
20
21
22
23
1. VOLUME Up/Down Buttons
2. Display
3. SET Button
4. FM Antenna
5. PRESET Button
6. OPEN Button
7. Remote Sensor
8. iPod Adjustment Knob
9. Left Speaker
10. Left Battery Compartment
(Bottom of Unit)
11. Left Unit “Leg”
(Bottom of Unit)
12. iPod Compartment with
Connector & Inter-
changeable Universal Docks
13. TUNE Up/Down/
Skip
n / o Buttons
14. PLAY/PAUSE (
®p) Button
15. BASS Button
16. Power Button
17. Headphones Jack
18. MODE Button
19. “Grooves” for nano adapter
20. Right Speaker
21. LINE IN, A/V OUT &
DC IN Jacks (Rear of Unit)
(LINE IN CABLE PART NO.
E12-00998-01, A/V CABLE
PART NO. E12-00992-01, AC
ADAPTER PART NO.
E18-00418-01*)
22. Right Battery Compartment
(Bottom of Unit)
23. Right Unit “Leg”
(Bottom of Unit)
*Consumer Replaceable Part
(See page 17 to order.)
