La Crosse Technology Wireless Temperature Station Portable Radio User Manual



13
Receiver Low
battery indicator
LCD Screen and settings:
Transmitter Low
battery indicator
Outdoor Temperature
in °F/°C
Outdoor Reception
Signal icon*
Indoor
Temperature in °F/°C
Time
Sensor identification No.
(shown when more than
one sensor is used)
14
*When the signal is successfully received by the Temperature Station, this icon will be switched
on. (If not successful, the icon will not be shown in LCD) So the user can easily see whether the
last reception was successful (icon on) or not (icon off). On the other hand, the short blinking of
the icon shows that a reception is being done now.
For better distinctness the LCD screen is split into 3 sections displaying the information for time,
indoor temperature, and outdoor temperature.
Section 1 - TIME
Display of time.
Section 2 - INDOOR TEMPERATURE
Display of indoor temperature
Section 3 - OUTDOOR TEMPERATURE
Display of the outdoor temperature
15
MANUAL SETTING:
12/24- HOUR TIME DISPLAY SETTING AND TEMPERATURE UNIT (°C/°F) SETTING
To display the time in 12-hour or 24-hour mode (default setting: 12h):
1. In normal display mode, press and hold the SET key for about 3 seconds. The "12h" or
"24h" digit will be flashing.
2. Press the + key to set the desired time display mode.
3. Press shortly the SET key to advance to the MANUAL TIME SETTING.
Note:
When the time display is set as 12-hour mode, the temperature unit will be fixed to °F; when the
time mode is in 24-hour, the temperature unit will be fixed to °C.
Flashing
16
MANUAL TIME SETTING
Set the time of Temperature Station by the following steps:
1. The hour digit of the time display will be flashing.
2. Press the + key to adjust the hour (Press and hold to allow fast advancing). Press SET
key to confirm and go to the minute setting.
3. The minute digit will be flashing. Press the + key to adjust the minute (Press and hold to
allow fast advancing).
4. Press SET key once more to return to normal display.
VIEWING THE MINIMUM AND MAXIMUM RECORDS:
To view the MIN/MAX indoor and outdoor temperature records:
1. Press the MIN/MAX key once to view the minimum indoor and outdoor temperature.
Minutes
(flashing)
Hours
(flashing)
