iH6_USB_new docks_ IB_8_11.fh10 12/19/06 9:19 AM Page 7
Install/Replace the Remote Control Batteries
The remote control batteries are already installed at the factory. When the remote control
stops operating or its range seems reduced, replace the batteries with new ones.
1. The battery door is located on the back end of the unit.
2. Press to release the battery door latch.
3. Insert one “CR2032” 3-volt lithium batteries. Make sure the polarity (the + and – side
of the battery) is correct.
4. Replace the battery holder back in the remote control.
NOTE: PLEASE DISCARD BATTERIES PROPERLY
Using The Remote Control Unit
Button
Button..............
Presets Select Button
EQ
Button..............Set Treble, Bass and Balance
settings for best sound
Radio Button..........Selects Radio function, AM and
FM1 and FM2 radio bands
Snooze/Dimmer Button
.....Lowers volume levelVolume
_
Button
.....Raises volume levelVolume + Button
The Remote Control controls basic functions on the iH6 and certain iPod
®
functions when the iPod
®
is docked in the iH6.
For best results, use the remote control within 12 feet of the unit.
5
Power On/Off Alarm
Reset Button
Turns iH6 ON or OFF
or reset alarm when
alarm is sounding
Skip to previous or next track when
iPod is playing, or HOLD to scan
current playing track. In radio mode,
press to tune stations. HOLD to scan
radio stations.
Cycles through AM
or FM radio presets
Snooze mode when
alarm sounds,
otherwise dims
display
Mute Button
Mutes volume
iPod Play/Pause Button
Selects iPod and
plays track. In play
mode , press to pause
Battery
door
