Install/Replace Backup Battery
The iH6 uses a backup battery system to provide continuous alarm operation and clock settings
in the event of a power failure. If the Battery Low Icon located on the left of the display is flashing,
it is time to replace the backup batteries.
Please make sure the AC adaptor is connected, otherwise
all settings may be lost during battery replacement.
Open the battery compartment cover located on the bottom of the unit. Insert 2 “AA” batteries
as indicated. We recommend the use of alkaline batteries for longer life.
Batteries information:
• Do not mix old and new batteries.
• Do not mix alkaline, standard (carbon -zinc) or rechargeable (nickel-cadmium) batteries.
Replacing iH6 Backup Batteries
4
Using the iH6
Radio
Setting up Antennas
a) Snap AM loop antenna into provided stand, then plug AM antenna cable into
ƹ AM Loop Antenna socket on back of unit.
Move antenna 12” away from unit for best reception.
b) Extend
FM Antenna (on back of unit) fully for best reception. Do not strip, alter or attach to other antennas.
Tuning and Playing the Radio
a) Press the ᕧ Radio Button to select radio play mode. Press as needed to select AM, FM1 or FM2 radio band.
b) Turn the Set Wheel to tune radio to a desired station.
c) To memorize the current station as a preset, press and hold
ᕨ Preset Button 1,2,3 or 4. Repeat steps a,b,and c to preset up
to 12 stations (4 AM, 8 FM). To listen to a preset station at any time, simply press the desired preset button.
d) Turn the ᕦ Volume Wheel to adjust iH6 volume up or down.
e) Press the EQ Button to select Treble, Bass or Balance. Turn the Set Wheel to adjust settings. EQ settings for iPod and radio
mode are independent.
f) Press
Ƹ Alarm Reset/Power Off Button to turn iH6 and iPod off.
Using the Line-in and Line-out Jacks
a) An audio patch cord comes with the iH6. Use it to play nondocking iPods or other audio devices through the iH6 ƿ Line-in Jack
(one end in the device’s line out or headphones jack, the other in the iH6 line in jack). Make sure there is no iPod docked in the
iH6 when using the line-in jack (however, you can charge shuffle while using line-in). Press the iPod Button.
b) Use the
ƻ Line Out Jack to connect the iH6 to the line-in jack of other audio devices such as a tape recorder or amplifier.
The Volume Wheel of the iH6 does not control line-out volume (adjust on attached device instead). The Line Out Jack is not
recommended for headphones.
Using Sleep Mode
Sleep mode lets you sleep to your iPod or the radio, gradually lowering the volume until the unit shuts off at the selected time.
a) Press the
µ Sleep Button to select an amount of time before the iH6 will turn off: 120, 90, 60, 30 or 15 minutes.
b) Turn the Volume Wheel to set the sleep volume (this volume setting is separate from your standard volume setting).
Using Dimmer
a) Press the ³ Snooze/Dimmer Button during normal operation to adjust brightness of LCD display.
