4
quick start: connections
Connect the provided
connector cable from the
back of the subwoofer to
the back of the receiver and
tighten screws.
Attach a speaker cable from the right speaker (R speaker) and left
speaker (L speaker) jacks on the back of the receiver to the jack on
the back of each matching speaker.
1: subwoofer 2: speakers
Plug the AC cable on the
back of the iH51 subwoofer
into a working wall socket
Remove the battery
compartment door on the
bottom of the receiver and
insert 2 AA batteries (match
+ and - polarity to diagram in
compartment). Replace door.
4: power
5: backup
batteries
sub level
to receiver
speaker r
subwoofer
receiver
Snap the AM antenna into the
provided stand, then plug the
antenna cable into the socket
on the back of the iH51. Move
the antenna 12” away.
3: antenna
sub level
to receiver
speaker lspeaker r
speaker lspeaker r
speaker r speaker l
