Icom IC-M32 Portable Radio User Manual



32
OPTIONS
New2001New2001
13
D BATTERY CASE AND PACK
BP-223
BATTERY CASE
Battery case for 6 × AA (R6) alkaline cells.
BP-224 Ni-Cd
BATTERY PACK
7.2 V/750 mAh Ni-Cd battery pack.
D CHARGERS
BC-119N
DESKTOP CHARGER
+ AD-103
CHARGER ADAPTER
+ BC-145
AC ADAPTER
For rapid charging of battery packs. An AC adapter is supplied with
the charger depending on versions. Charging time: approx. 1.5 to 2
hours
BC-121N
MULTI
-
CHARGER
+ AD-103
CHARGER ADAPTER
(6 pcs.)
+ BC-124
AC ADAPTER
For rapid charging of up to 6 battery packs (six AD-103s are re-
quired) simultaneously. An AC adapter should be purchased sepa-
rately. Charging time: approx. 1.5 to 2 hours.
BC-150
DESKTOP CHARGER
+ BC-147A/E or BM-95V
AC ADAPTER
Used for regular charging of battery pack. The same as supplied
with the transceiver. Charging time: approx. 8 hours
D BELT CLIPS
MB-68
BELT CLIP
The same as supplied with the transceiver.
MB-74N
BELT CLIP
Exclusive alligator-type belt clip.
MB-87
SWIVEL BELT CLIP
Belt clip for swivel type.
D DC CABLES
CP-17L
CIGARETTE LIGHTER CABLE
Allows to charge the battery pack through a 12 V cigarette lighter
socket. (For BC-119N)
OPC-515L/OPC-656
DC POWER CABLES
Allows to charge the battery pack using 13.8 V power source in-
stead of the AC adapter.
OPC-515L: For BC-119N
OPC-656 : For BC-121N
