30
EMC CLARiiON CX300, CX500, and CX700 Initialization Guide
Installing Optional Navisphere 6.X Software
3. On the laptop desktop, enter an IP address, subnet mask, and
default gateway for your connection. Be sure the IP address is
unique to this connection.
You can enter the same mask and gateway specified in step 12 on page
20, but you must assign an IP address not used by SP A or B; for example,
10.4.12.138 rather than 136 or 137.
4. Open the PPP connection icon on your desktop taskbar, and
disconnect the laptop-array serial connection.
Installing Software Options
To install software do the following:
1. If you plan to use Navisphere Manager, MirrorView, SnapView,
SAN Copy, Analyzer, or Access Logix software, use the LAN
connection to install the appropriate files listed below from the
Navisphere Manager CD-ROM and the Access Logix CD-ROM.
Install them as part of the same software installation, as described
in the Navisphere Manager online help (refer to the section on
Installing software packages).
• ManagementUI (required for Manager)
•MirrorViewUI
• SnapViewUI
•SANCopyUI
•AnalyzerUI
• File on your Access Logix CD-ROM
All the UIs listed above are on the Navisphere Manager CD-ROM.
2. If you have SnapView, MirrorView, SAN Copy, or Analyzer
software, install those drivers from the SnapView, MirrorView,
SAN Copy, or Analyzer CD-ROM in a subsequent software
installation.
