TV components
3
Left side view
Right side view
Remote control
Number Component Description
1 Headphone Insert headphones
into this jack for
private listening. The
external speaker is
muted.
2 Vol. Press to adjust volume
up or down.
3 Brightness Press to adjust the
brightenss up or
down.
Number Component Description
1 RF IN Connect an antenna to
this jack.
2 AV IN Connect an AV device such
as a VCR or DVD player to
this jack.
3 Power/Charge LED LED status:
Green=TV on
Red=Built-in battery is
recharging
OFF= built-in battery is
fully charged
4 DC 9V Connect the provided
power adapter to this jack.
VOL.
Number Button Description Function
1 AUTO Press to search for
channels automatically.
2 DISPLAY Press to display channel
information.
3 MENU Press to access the TV
menu.
4
ENTER
Press to navigate the
on-screen menu and to
confirm your selection.
5 Number keys Press to select channels.
6 GUIDE Press to display program
information for digital
stations.
7 INPUT Press to switch between
TV and AV IN.
8 MUTE Press once to mute. Press
again to restore the sound
9 AUDIO Press to select from
available audio
soundtracks.
10 CH+ Press to select the next
channel.
11 CH- Press to select the
previous channel.
