Contents
Dynex 7" Portable Digital
TV DX-7HTV-09
Contents
Important safety instructions...........................................................2
Package contents.............................................................................. 2
TV components ................................................................................2
OSD menu ........................................................................................ 4
WARNING: The TV will not work when it is moving........................... 4
Troubleshooting ...............................................................................5
SpecificatSpecifications.................................................................... 5
Legal notices ....................................................................................5
90-Day Limited Warranty ................................................................. 7
Important safety instructions
• To prevent from fire or electric shock, do not expose the TV to rain
or moisture.
• Do not place the TV on an unstable cart, stand, tripod, bracket, or
table to prevent it from falling.
• Keep the TV away from strong magnets, heat sources, direct
sunlight, and excessive dust.
• If you move the TV from a cold to a warm location, wait for about
one hour before operating it, or leave the TV turned on until the
moisture evaporates to prevent moisture from condensing inside
it.
• Make sure that the TV is installed in accordance with the
instructions and illustrations provided in this manual.
• Do not push objects of any kind into the TV through openings. Do
not spill or spray liquid of any kind on or in the TV (this may result
in a fire or electric shock).
• Do not place anything heavy on the TV.
• To ensure proper ventilation and proper operation, never cover or
block the slots and openings with a cloth or other material.
• Keep the TV away from an open flame such as a fire, or candle.
• Do not attempt to take apart the cabinet. There is a risk of electric
shock or exposure to laser radiation. Contact qualified service
personnel if the TV needs repair.
• When cleaning, make sure the TV is unplugged from the power
source. Do not use liquid cleaners or aerosol cleaners. Use a cloth
lightly dampened with water for cleaning the exterior of the TV
only.
Package contents
The following items are in this package
• 7'' portable digital TV
• Remote control with battery
• Audio/video cable
• Power adapter
• Car power adapter
•L-shaped F connector
•This user guide
TV components
Front view
Number Component Description
1 IR Sensor Recieves information from
remote control.
2 POWER Press to turn the TV on and off.
3 MENU Press to open and close the TV
menu.
4
CH +/-
Press to highlight menu
options.
Press to select the previous or
next channel.
5 ENTER Press to confirm a menu
selection.
6 INPUT Press to switch between TV and
AV IN modes.
7 WIDE Press to select Widescreen or
Auto formats.
