- 10 -
5. Repeat steps 2 - 4 to enter additional tracks. You can store upto 32 programs in
memory.
Notes: If the PLAY/PAUSE Button is pressed before the MEMORY Button is pressed to
store a track, the track will not be programmed, and the disc will start playing
from the first selected track.
Any track can be programmed to play more than once.
If you press the STOP Button during MEMORY mode, the entire program
will be erased from memory.
LISTENING TO PROGRAMMED TRACKS
Program your selection of tracks by following the procedure shown above.
Press the PLAY/PAUSE Button.
Disc play will start at the beginning of the first programmed track.
TO CLEAR THE PROGRAM MEMORY
If the disc is playing, press the STOP Button.
Press the STOP Button again. All the programs will then be erased from memory.
The program memory will also be cleared if the Function Selector is changed to another
function, or if the power is switched off.
RECORD PLAYER
RECORD PLAYER UNPACKING - Before playing any records:
A. 45 RPM ADAPTOR
B. TURNTABLE
C. PICK UP ARM
D. 33/45 SPEED SELECTOR
E. TRANSIT SCREW
* If this is the first time the record player is used,
screw the transit screw clockwise until tight.
Failure to do this will cause vibration and hum.
* Unlock the PICK UP ARM from the PICK UP ARM
REST.
* Remove the stylus cover by pulling it gently forward, away from the HEAD SHELL.
1. Turn the unit on using the STANDBY/ON button.
2. Set the Function Selector to PHONO position.
3. Lift the DUST COVER and select the speed to suit the record you are about to play
using the 33/45 RPM SPEED SELECTOR switch.
4. Place the record on the TURNTABLE so that the SPINDLE protrudes through the
centre hole in the record.
5. Raise the PICK-UP ARM by grasping it lightly at the FINGER LIFT located on the
HEAD SHELL and gently move it to the left towards the record. The turntable will
now start rotating. Move the stylus to the selected point above the record. Lower the
PICK-UP ARM gently onto the record groove.
6. At the end of the record, the PICK-UP ARM will return to its rest position and the
turntable will stop.
A
B
CD
E
