Curtis iP215UK-BLACK MP3 Docking Station User Manual



4
Features Defined
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
LCD Display View the time, AM Indicator, iPod Indicator, Radio Frequency, though this Liquid
Crystal Display.
IPOD Docking Station Connect your iPod, iPod mini, iPod nano.
PLAY/PAUSE Press the PLAY/PAUE button to play or pause an iPod playing.
REV Press the REV button to skip to previous a track on the iPod playing. Press and hold the REV
button to search backwards though a track on the iPod playing.
FWD Press the FWD button to skip to next track on the iPod playing. Press and hold the FWD
button to search forwards though a track on the iPod playing.
VOLUME Turn the VOLUME dial anti-clockwise to increase the volume and clockwise to decrease
the volume.
TUNING Turn the TUNING dial anti-clockwise to decrease the radio frequency and clockwise to
increase the radio frequency.
POWER Press the POWER button to turn unit on / off.
BUZZER . RADIO . IPOD/AUX Slide the BUZZER . RADIO . IPOD/AUX toggle switch to the
alarm sound wake to Buzzer / Radio / iPod or Aux mode.
AM . FM ST . IPOD/AUX Use the AM . FM ST . IPOD/AUX toggle switch to adjust the unit
between AM radio, FM ST radio, iPod / Aux mode.
CLOCK SET Use the CLOCK SET button in conjunction with the MIN and HOUR buttons to adjust
the clock time.
ALARM Use the ALARM button in conjunction with the MIN and HOUR buttonsto adjust the clock
time.
HOUR The HOUR button is used to adjust the hour when setting the clock.
MINUTE The MINUTE button is used to adjust the minute when setting the clock.
ALARM ON/OFF Press the ALARM ON/OFF toggle between alarm active or deactivate. Press
this button to stop alarm sound when the desired alarm time is reached.
SLEEP Press the SLEEP button to set the sleep timer from 0 ~ 60 minute.
SNOOZE Press the SNOOZE button to delay the alarm for 5 min. after the alarm sound.
AUX IN Use the AUX-IN jack to connect an iPod shuffle or other audio device to the unit .
AUX OUT Use the AUX-OUT jack to connect the player to external speakers.
VIDEO OUT Plug the yellow connector of an AV Cord in the VIDEO OUT to send a video signal
from a Video iPod to a source (TV) with a Video Input.
FM Antenna The FM Antenna is extendable and adjustable. An AM Antenna is built into the unit.
DIMMER Toggle the DIMMER switch between HI and LO to adjust the brightness of the LCD
Display.
AC Cord (120V/60 Hz) The attached AC (Alternating Current) Cord provides power to the unit.
BATTERIES Compartment (AAA size X2) The BATTERIES back-up will save the clock and
alarm settings in case of power outage. The display will not be active without AC Power (batteries
not included). NOTES: DO NOT MIX OLD AND NEW BATTERIES.
