Docking Station for the TPS-6X Crestron TPS-6X-DS
Triple-Lock Tilt Mechanism
The tiltable docking port on the TPS-6X-DS allows the touchpanel to be tilted at any
angle up to 45 degrees for optimal viewing and operation. The angle can be freely
adjusted during use or locked down at a fixed angle. A finger-operated latch can be
engaged at any time to lock the touchpanel securely to the docking station or left
unlocked for easiest removal after recharging. For a fulltime tabletop touchpanel
solution, the touchpanel and docking station can be semi-permanently attached
together using a special locking key pin provided.
Low Profile Base
Its sleek appearance belies a surefooted design offering excellent stability on any flat
surface. A single cable exits the rear of the docking station base, which can be
repositioned to exit the bottom for a very clean, cordless appearance when
permanently mounted.
Specifications
Specifications for the TPS-6X-DS are listed in the following table.
NOTE: The TPS-6X-DS is a passive device requiring no power; refer to TPS-6X
and TPS-6X-IMCW specifications for other power requirements.
TPS-6X-DS Specifications
SPECIFICATION DETAILS
Environmental
Temperature 32º to 112ºF (0º to 45ºC)
Humidity 10% to 90% RH (non-condensing)
Enclosure
Injection-molded plastic, high gloss black
finish, 45° to 90° tilt docking port, adjustable
friction clutch tilt mechanism, low-profile base,
integral cable assembly
Dimensions
Height
4.25 in (10.80 cm)
6.00 in (15.25 cm) with touchpanel mounted
Width 6.96 in (17.67 cm)
Depth
7.03 in (17.84 cm)
6.53 in (16.57 cm) without grommet
Weight 1.25 lbs (0.57 kg)
Included Accessories
TPS-6X-IMCW Interface Module
Available Accessories
PW(I)-1215 12 Volt Power Pack
2 • Docking Station for the TPS-6X: TPS-6X-DS Operations Guide – DOC. 6576B
