Crestron BB-6X-DSW Pre-Construction Wall Mount Back Box
Pre-Construction Wall Mount
Back Box: BB-6X-DSW
Description
The Crestron
®
BB-6X-DSW back box provides a UL
®
-listed, recess-mounted steel
enclosure for the TPS-6X-DSW Wall Mount Docking Station. Designed for pre-
construction applications, the BB-6X-DSW permits fastening to the left or right side
of a stud in a framed wall prior to installation of sheet rock. Conduit knockouts are
provided on the top and bottom to accommodate a variety of fittings and a blank
cover plate is included.
NOTE: If mounting into a material other than drywall (for example, wood lectern,
concrete or rock) use the cutout template, available in the post-construction kit
MMK-6X-DSW or TMK-6X-DSW.
NOTE: For concrete and rock mounting material, allow for proper ventilation
before mounting the TPS-6X-DSW.
The table below lists all parts included with the BB-6X-DSW.
Supplied Hardware for the BB-6X-DSW
DESCRIPTION PART NUMBER QUANTITY
Assembly, Wall Mount, Back Box 4507462 1
Metal, Plate, Blank, Cover 2022825 1
Screw, #06-32 x 1-½”, Pan, Phil 2007254 4
Screw, #08-8B, ¼”, Pan, Phil 2007277 1
Installation Guide – DOC. 6728A Pre-Construction Wall Mount Back Box: BB-6X-DSW • 1
