Pre-Construction Wall Mount Back Box Crestron BB-6X-DSW
Mounting TPS-6X-DSW Docking Assembly and BB-6X-DSW Back Box – Exploded View
TPS-6X-DSW
DRYWALL
BB-6X-DSW
SCREWS (4) #06-32 x 1½"
PAN, PHIL (2007254)
Other Mounting Option Accessories
If too much of the mounting plate is exposed after the drywall is cut, you may need
to patch the area. Crestron provides the following accessories:
• MMK-6X-DSW (Doc. 6779) – for larger repairs and to fill in larger
irregularities around the opening (requires plastering).
• TMK-6X-DSW (Doc. 6780) – for smaller repairs and to provide a smooth
edge at the opening. This option provides a finished appearance and is
preferred when wallpaper is hung.
The manuals for the MMK-6X-DSW and TMK-6X-DSW are available from the
Crestron website.
8 • Pre-Construction Wall Mount Back Box: BB-6X-DSW Installation Guide – DOC. 6728A
