Cobra Electronics MR HH100 VP Portable Radio User Manual



25
Nothing comes close to a Cobra
®
24
English
Wrist Strap, Belt Clip, Spkr/Mic
Jack And Waterproof Pouch
Installation Installation
Batteries And Charger Jack
Wrist Strap, Belt Clip, Spkr/Mic Jack And Waterproof Pouch
The radio is shipped with a Wrist Strap, Belt Clip and Waterproof Pouch in the
package. The Speaker/Microphone Jack can be used with additional accessories.
Contact your local Cobra
®
dealer or Cobra
®
directly for optional accessories.
Wrist Strap
Your radio comes with the Wrist Strap already
attached. It can be easily removed if you choose
not to use it.
Belt Clip
Use the Belt Clip to carry your radio around with
you. Simply squeeze the clip and place it where
you prefer.
External Speaker/Microphone Jack
Your radio can be fitted with an optional External Speaker/Microphone
(not included), freeing your hands for other tasks. Contact your local Cobra
®
dealer or Cobra
®
directly for optional accessories.
To Attach The External Speaker/Microphone:
1. Open the speaker/microphone tab on top
of the radio.
2. Insert the plug into the speaker/microphone jack.
Waterproof Pouch
Use the included Waterproof Pouch to not only keep your radio dry,
but also dust and dirt free.
To Enclose The Radio In The Waterproof Pouch:
1. With the CobraMarine
logo facing up,
slip radio, face up, into opening under
Velcro
®
flap at the bottom of the
waterproof pouch.
2. Turn pouch and radio over so that the
CobraMarine
logo is facing down.
3. Roll bottom of pouch (between Velcro
®
pieces) towards upper piece of Velcro
®
.
4. Secure bottom piece of Velcro
®
to
upper piece of Velcro
®
.
Batteries And Charger Jack
Your radio includes four (4) rechargeable NiCD (Nickel-Cadmium) Batteries
(part No. NiCB) and a wall mount charger (part No. WWC) in the package.
Your wall charger is capable of recharging one (1) radio with batteries
installed in battery compartment.
You should fully charge the included rechargeable NiCD batteries before
using your radio for the first time.
Installing The Batteries
To Install Or Replace Batteries:
1. Remove belt clip by releasing belt clip latch
and sliding clip down.
2. Pull down on the battery door latch to remove
the battery compartment cover.
3. Insert the rechargeable NiCD batteries
(part No. NiCB) according to polarity markings.
4. Replace battery compartment cover and belt clip.
NOTE
Your radio can also be operated with four (4)
standard AAA alkaline batteries. Always use
high quality alkaline batteries. Position batteries
according to polarity markings.
NOTE
Contact your local Cobra
®
dealer or Cobra
®
directly for optional accessories.
WARNING
Only the rechargeable NiCD batteries
(part No. NiCB) can be recharged.
Remove Belt Clip
Remove Battery Cover
Insert Four (4) Batteries
Belt Clip
Speaker/Microphone Tab
Waterproof Pouch
Wrist Strap
