DXZ848RMC 13
English
2. Press and hold the [A-M] button for 1 second
or longer to turn off the MAGNA BASS
EXTEND effect. “M-B EX” goes off from the
display.
Note:
• When “ADF-1”, “ADF-2” or “ADF-3” is selected for
ADF (Anti Distortion Filter), setting of MAGNA
BASS EX cannot be performed.
Setting the Anti Distortion Filter
The adopted “Liveliness Enhancement Filter”
and “Sound Tone Compensation” functions al-
low well-modulated realistic playback without af-
fecting the characteristics of the original sound
tone.
This unit are provided with 3 types of sound
tone effects stored in memory. Select the one
you prefer.
∗ The factory default setting is “ADF OFF”.
Each time you press the [ADF] button, the tone
effect changes in the following order:
“ADF-1” ➜ “ADF-2” ➜ “ADF-3” ➜
“ADF OFF” ...
• ADF-1 : suitable for the genuine speakers
• ADF-2 : suitable for separate speakers
• ADF-3 : suitable for coaxial speakers
• ADF OFF : no sound effect
Notes:
• The volume changes each time the ADF (Anti Dis-
tortion Filter) setting is switched. Turn down the
volume and the sub-woofer volume before per-
forming a switching operation.
• Sufficient effects cannot be obtained with some
speaker systems. In such cases, adjust the vol-
ume.
Adjusting the tone
Press the [A-M] button and select the item to
adjust. Each time you press the [A-M] button,
the item changes as following order:
●When “ADF 1, 2, 3” is set
“SW-VOL 0” ➜ “BALANCE 0” ➜ “FADER 0”
➜ Last function mode.
●When “ADF OFF” is set
“SW-VOL 0” ➜ “BASS
ÅÅ
ÅÅ
Å
GAIN
ÎÎ
ÎÎ
Î
” ➜
“TREB
ÅÅ
ÅÅ
Å
GAIN
ÎÎ
ÎÎ
Î
” ➜ “BALANCE 0” ➜
“FADER 0” ➜ Last function mode.
Note:
• As subwoofer is effective, “SW-VOL 0” can be
selected.
Adjusting the Subwoofer
∗ The factory default setting is “SW-VOL 0”
∗ This function can be adjusted only when the
subwoofer output is set to “ON”. For details on “Se-
lecting the Subwoofer”, refer to the section “Op-
erations Common to Each Mode” of each owner’s
manual.
1. Press the [A-M] button, “SW-VOL 0” appears
in the display.
2. Turning the [ROTARY] knob to select from –6
to +6.
3. When the adjustment is complete, press the
[A-M] button several times until the function
mode is reached.
Adjusting the bass (Gain,
Frequency, Q-curve)
This adjustment can be performed when the
ADF (Anti Distortion Filter) is set to “ADF OFF”.
1.
Press the [A-M] button and select
“
BASS
ÅÅ
ÅÅ
Å
GAIN
ÎÎ
ÎÎ
Î
”.
2. Turning the [ROTARY] knob clockwise em-
phasizes the bass; turning it counterclock-
wise attenuates the bass.
∗ The factory default setting is “BASS
ÅÅ
ÅÅ
Å
G 0
ÎÎ
ÎÎ
Î
”.
(Adjustment range: –6 to +8)
3. Press the [a] or [d] button to select
“BASS
ÅÅ
ÅÅ
Å
F 50
ÎÎ
ÎÎ
Î
”.
Turninng the [ROTARY] knob clockwise or
counterclockwise to select the frequency.
∗ The factory default setting is “BASS
ÅÅ
ÅÅ
Å
F
50
ÎÎ
ÎÎ
Î
”.(Adjustment 50/80/120 Hz)
4. Press the [a] or [d] button to select
“BASS
ÅÅ
ÅÅ
Å
Q 1
ÎÎ
ÎÎ
Î
”.
Turning the [ROTARY] knob clockwise or
counterclockwise to select the Q-curve.
∗ The factory default setting is “BASS
ÅÅ
ÅÅ
Å
Q 1
ÎÎ
ÎÎ
Î
”.
(Adjustment 1/1.25/1.5/2)
5. When the adjustment is complete, press the
[A-M] button several times until the function
mode is reached.
Adjusting the treble (Gain,
Frequency)
This adjustment can be performed when the
ADF (Anti Distortion Filter) is set to “ADF OFF”.
1.
Press the [A-M] button and select
“
TREB
ÅÅ
ÅÅ
Å
GAIN
ÎÎ
ÎÎ
Î
”.
Basic Operations
