BT Freeway Mini – Edition 2 – 18.05.04 – 5916
Using your mobile radios
3. Release when you have finished speaking. Your
listener will hear a beep (called a roger tone) to confirm
you have finished speaking. They can then speak to you.
When you are transmitting you will notice the LCD
outline stops flashing and becomes permanently lit.
Sending call tone
To alert other radios in your group that you want to
communicate with them, you can send a call tone.
This can also help you find a misplaced radio.
1. Press . Both your radio and the other radios in your
group will sound a call tone.
Listen to another radio
When switched on, your BT Freeway Mini is always in
standby reception when the is not being pressed and
you are not changing any of the settings. Provided the
other radio is using the same channel, you will hear
them speak.
PTT
PTT
It is recommended that you do not
use your radios closer than 1.5
metres apart to avoid interference.
Your radios have a range of up to
3km. However, the range is
affected by the environment or
terrain in which it is being used.
To obtain the maximum range,
use in clear line of site situations.
Obstructions between the radios
(e.g. buildings) will greatly reduce
the range achieved.
