Product Description
You have purchased one of the finest pendant loudspeakers available today. Please
familiarize yourself with this product by reading and reviewing the following descrip-
tions and diagrams.
These loudspeakers include a "spiderless" woofer that utilizes a high-gauss ferroflu-
id to guide the voice coil through the magnetic field.The benefits over conventional
woofers with cloth spiders are several, including the ability to constantly adjust voice
coil alignment, extend linear excursion, and the most efficient path for cooling the
voice coil.
In addition, the use of metal-alloy cone structures provides several benefits over the
usual paper or plastic cone, such as elimination of cone flex or "break-up" in the
operating ranges, additional thermal path for the voice coil to stay cool, and an
extremely stable cone structure unaffected by the environment.
The pendant loudspeaker is a full-range, wide dispersion system providing overhead
sound coverage where ceiling structures are high but the sound needs to be closer
to the audience/listener. Cable kits are provided for use as safety and main drop
cables.
Settings for 70V and 100V high-impedance systems, as well as a low-impedance
(16-ohm) position, are provided.
All models feature a removable snap-lock input connector, providing easy wire con-
nection for input as well as loop-through to the next speaker.
