I 4987
Drive units
Nominal impedance
Frequency response
Sensitivity
Crossover frequency
Recommended
amplifier power
Frame size
Cut-out size
Min depth required
Net weight
Finishes
1x 25mm (1in) high-frequency
1x 165mm (6.5 in) mid/bass
8Ω
50Hz – 20kHz ±3dB
89dB spl (2.83V,1m)
3.5kHz
20W – 130W continuous into
8Ω on unclipped programme.
Diameter: 225mm (8.9in)
Diameter: 206mm (8.1in)
73mm (2.9in) from ceiling surface
1kg (2.2lb)
Semi-matt white suitable for
customising or pre-painting
CCM20
