Operation (continued)
Note:
208 / 120V<120D Output Voltage (L1-L2)=208V, Output Voltage (L1,L2)=120V and L1 leads L2 120 degrees
208 / 120V<240D Output Voltage (L1-L2)=208V, Output Voltage (L1,L2)=120V and L2 leads L1 120 degrees
240 / 120V<180D Output Voltage (L1-L2)=240V, Output Voltage (L1,L2)=120V and L1 leads L2 180 degrees
Self-Test Is Running
TESTING BATTERY
LOAD1 = XXX% X.XKW
Additional Self-Test
Ifaself-testisinitiatedafterstartup,theLCDwilldisplayamessage.
Configuration Menu
TheUPSoutputvoltageissetat208/120V~whentheUPSisshippedfromthefactory.InordertochangetheoutputvoltageoftheUPS,you
firstneedtoenter“ONBATTERYMODE”bycold-startingtheUPS.(Thebatterymustbeatleastpartiallychargedforthisoperationto
succeed.)IftheUPSison,pressandholdthe“OFF”buttonuntilyouhearabeep,disconnectanyconnectedequipmentanddisconnectthe
UPSfromitsACpowerinput.AftertheUPSisdisconnectedfromACpower,pressthe“ON/MUTE”buttonuntilyouhearabeep.TheLCD
screenwillshow“ONBATTERYMODE”andanalarmwillsoundperiodicallytoinformyouthattheUPSisusingbatterypower.Silence
thealarmbypressingthe“ON/MUTE”button.
AftertheUPShasentered“ONBATTERYMODE”,presstheSCROLLUPandSCROLLDOWNbuttonssimultaneouslyforlongerthan
1second.TheUPSwillbeepandtheLCDwillshowtheSET-UPscreen(1).PresstheSCROLLUP/SELECTbuttontoenterthe“UPSSET-UP”
procedure(2).Press the SCROLLUP/SELECT buttonagain toenter the“OUTPUT SELECT”procedure(3). Thereare 3output voltage
selections.PresstheSCROLLDOWNbuttontoscrolltothedesiredoutputvoltageselection(3)-(5)andthenpresstheSCROLLUP/SELECT
buttontoselectit.TheLCD willreturnto the“OUTPUTSELECT”screen(2). PresstheSCROLLDOWNbuttontoreachthe SET-UP
screen(1)andpresstheSCROLLDOWNbuttonagaintoexittheSET-UPprocedure.TheLCDshouldbebackto“ONBATTERYMODE”.
Pressthe“OFF”keyuntilyouhearabeep,andtheUPSwillsavetheselectedoutputvoltageparameter.RestoretheACpowerinputofthe
UPSandpressthe“ON”keytoturnontheUPSandusetheSCROLLDOWNbuttontoscrollthroughthebasicpowerconditionsdisplays
andconfirmthattheoutputvoltagehasbeenchangedtothedesiredvalue.
EconomyMode(ECO)isahigh-efficiencyoperatingmodeinwhichthedoubleconversionprocessissuspended.Incomingpowerisfiltered,
andiftheinputvoltageiswithin+/-10%ofthenominalvoltage,itispassedthroughtoconnectedequipment.Iftheinputvoltagegoesoutside
ofthisacceptablerange,theunitautomaticallyreturnstoitsOnlineModetoprovideahighlyregulatedoutputderivedfromthesystem’s
inverter.Ifvoltagesubsequentlyreturnstotheacceptablerange,theunitwillreturntoitshighefficiencymode.
i
ECO
Scroll
Disable
Select
ECO
Exit
Enable
Select
ii
i
ECO
Scroll
Disable
Select
ECO
Exit
Enable
Select
ii
