Customized load
management
receptacles
3 individually controllable single outlet 5-15/20R load banks
Overload protection Via 40A input circuit breaker
INPUT
Maximum input
amps
24A with L5-30P input / 30A hardwired
Input connection
type
L5-30P (back panel terminal block enables hardwire input (see manual)
Input cord length 10 ft.
Recommended
Electrical Service
120V 30A
BATTERY
Full load runtime With L5-30P plug - 7.5 minutes (2880 watts) / With hardwire input - 5 minutes (3600 watts)
Half load runtime With L5-30P plug - 19 minutes (1440 watts) / With hardwire input - 13 minutes (1800 watts)
DC system voltage 48VDC
Replacement
Battery Cartridge
RBC54 (qty 2)
VOLTAGE REGULATION
Voltage regulation
description
Automatic Voltage Regulation (AVR) circuits maintain clean, regulated computer-grade 120V nominal output, without
using battery power, during brownouts to 83V and overvoltages to 145V
Overvoltage
correction
Input voltages between 127 and 145V AC are reduced by 12%
Brownout correction Input voltages between 96 and 108V AC are boosted by 12%
Severe brownout
correction
120V only: Input voltages between 83 and 95 are boosted by 24%
LEDS ALARMS & SWITCHES
Front panel LEDs 5 front panel LEDs - Green POWER LED, Green VOLTAGE CORRECTION LED, 3 color BATTERY CHARGE LED, 3
color OUTPUT LOAD LEVEL LED, red BATTERY WARNING LED.
Alarms 3 function audible alarm indicates power failure conditions (4 short beeps every 10 seconds), overload (continuous short
beeps) and low battery (continuous tone)
Switches Yes, includes 2 front panel mounted push-button switches for system enable, self-test and alarm cancel functions. Back
panel includes battery charge level switch for internal or external battery configurations
SURGE / NOISE SUPPRESSION
AC surge
suppression
570 joules
AC suppression
response time
Instantaneous
EMI / RFI AC noise
suppression
Yes
PHYSICAL
Shipping weight
(lbs)
124
Shipping weight (kg) 56.3
Shipping
Dimensions
(HWD/in)
13.2 x 23.6 x 22.8
Shipping
Dimensions
(HWD/cm)
33.5 x 59.9 x 57.9
Unit weight (lbs) 102
Unit weight (kg) 46.3
