Phonecell
®
SX5T CDMA2000 24 User Manual
Windows 98 Setup for Data & PC Fax
Contact your service provider to determine data/PC fax service availability, then follow these steps.
1. Connect and Select Data Ports.
Serial Connection – default setting (Allows PC Fax, 1X Data and Circuit Switched Data)
· Use a Telular serial cable (part #1L01A042 or 81025801) to connect the computer’s
serial port to the SX5T’s data port.
· Enter Configuration Mode.
Press
<lock code> .
· Set the SX5T Data Port to Serial.
Press .
Modem/Phone Connection (Allows PC Fax and Circuit Switched Data)
· Use a standard telephone cord to connect the computer’s modem out port to either
of the SX5T’s phone (RJ11) jacks.
· Enter Configuration Mode.
Press
<lock code> .
· Set the SX5T Data Port to RJ11.
Press .
2. Set Baud Speed.
· Enter Configuration Mode.
Press
<lock code> .
· For fax, set speed to 19200. Press .
· For data, set speed to 115200. Press .
3. Install the SX5T as a new modem by opening the Start > Settings > Control Panel then clicking
on the Modems phone icon.
