PLM100JWAE-06 PLM100JWAF-06
PLM150JWAE-06 PLM150JWAF-06
Adapters, Clamps, and Canadian Spec. Motor
(Includes 25’ Cord w/Straight Plug)
PLM100JWAE-12 PLM100JWAF-12
PLM150JWAE-12 PLM150JWAF-12
Adapters, Clamps, and U.S.A. Spec. Motor
(Includes 3’ Cord w/Twist-Lok Plug)
PLM100JWAE-03 PLM100JWAF-03
PLM150JWAE-03 PLM150JWAF-03
Hoses, Adapters, Clamps, and U.S.A. Spec. Motor
(Includes 3’ Cord w/Straight Plug)
PLM100JWAE-04 PLM100JWAF-04
PLM150JWAE-04 PLM150JWAF-04
Adapters, Clamps, and U.S.A. Spec. Motor
(Includes 3’ Cord w/Straight Plug)
5
SPECIFICATIONS / MODEL DESCRIPTIONS
FIGURE 1 – Dimensions in inches (mm)
Table 1 - Filter Specifications
Model No.
PLM100 PLM150
Filter Area sq. ft. (m
2
) 100(9.3) 150(14)
Max. Rated Flow GPM (LPM)*
Residential 100(379) 150(568)
Commercial 37(140) 56(212)
Max. Operating Pressure PSI (kPa) 50(345) 50(345)
Max. Continuous Water
Temperature F(C) 104°(40°) 104°(40°)
* For best water clarity and filter cycle length, restrict
water flow to 50 GPM (189 LPM).
FIGURE 2 – Pressure Drop Curve
