5-1 Starting and Exiting
Chapter 5 Using the Utility Software
5-2 Names and Functions of Parts
a Menu bar
This shows the menus of the utility
software.
Click a menu name to display the
commands for executing functions.
• Settings menu
PC operation settings: Opens a dialog
box to select the language for screen
indications and operations, and to
enable or disable the FAM
connection (see page 48).
•Help menu
PC Utility manual: Shows the manual
(Help information) for the utility
software.
PC Utility version information: Opens
a dialog box showing the version
information for the utility software.
b Tree display
The menus for this unit appear in a tree
configuration.
Click the + sign to the left of a menu name
to display the submenus in the level below;
the + sign changes to a – sign. (Click the –
sign to close the submenu display.)
Click a menu item to display the operating
screen for the menu item in the operating
section.
