Using your RS 175 headphone system
RS 175 | 21
Selecting an audio input
If both analog and digital audio inputs are connected to different audio
sources, the headphone system enables you to toggle between the two
inputs.
̈ Push the AUDIO INPUT SELECTION switch up to listen
to an audio source
connected to the digital optical input (see page 13).
̈ Push the AUDIO INPUT SELECTION switch down to listen to an audio
so
urce connected to the analog input (see pages 14 and 15).
Adjusting the volume
̈ Press the Volume + button or the Volume – button repeatedly until the
volume is adjusted to the desired level. When the minimum or maxi-
mum volume setting is reached, you hear a beep in the headphones.
Muting/unmuting the headphones
̈ Press the HDR power button to mute the headphones.
̈ Press the HDR power button or any of the Volume +/– buttons to
c
ancel the muting.
Digital
Analog
Vol Vol
If the headphones are muted for 15 minutes, the headphones switch
off automatically to save energy.
