Manual Feed
Manual Feed allows you to feed stapled or unstapled sets of up
to 5 sheets of 20 lb. (80g/m
2
) to a maximum total weight of
100 lb. (400g/m
2
). The sets are fed by hand, one set at a time, for
processing by the machine.
Using the Manual Feed automatically turns off all Sheet Feeders.
You can, however, use the Insert Feeder(s) if they have been
enabled by a Supervisor using the Manual Feed Option explained
on page 4-8.
Constraints and Requirements
• Only use closed flap envelopes.
• This mode cannot be used to run fold only or inserts only.
• Sheet Feeders do not operate in this mode.
• The Envelope Sealer is always on (except for the Trial
Piece).
• The Batch Count is always off.
• Sets should contain sheets of the same length.
• This mode will not work with OMR.
Loading Material for Manual Feed Mode
Loading Insert Feeder(s)
Insert Feeder(s) will only operate if they have been enabled by a
Supervisor using the Manual Feed Option explained on page 4-8 of
this guide.
For a single Insert, load Insert Feeder F. For two Inserts, load Insert
Feeders F and G.
Booklets must be loaded into Insert Feeder F only and should be
loaded with the binding edge first.
Pre-folded Inserts should be fed with the open edge last.
Loading Envelope Feeder
Envelopes are loaded into Envelope Feeder E flap side up, flap last.
