29
English
EN
.asflesinASFcontainer
Audio codec Video codec Bit rate
Dolby Digital,
MP3, WMA,
Dolby Digital
Plus
MPEG 4
ASP
38.4 Mbps
H.264/AVC
HiP@4.2
25 Mbps
WMV9 45 Mbps
.mpgand.mpeglesinPScontainer
Audio codec Video codec Bit rate
PCM, DTS core,
MPEG, MP3
MPEG 1,
MPEG 2
40 Mbps
.vlesinFLVcontainer
Audio codec Video codec Bit rate
MP3, AAC H.264/
AVC upto
HiP@4.2
25 Mbps
H.263 38.4 Mbps
.3gplesin3GPcontainer
Audio codec Video codec Bit rate
AAC, HE-AAC MPEG 4 ASP 38.4 Mbps
H.264/
AVC upto
HiP@4.2
25 Mbps
max
.rm,.rv,and.rmvblesinRMcontainer
(AvailableonlyinAsiaPacicandChina)
Audio codec Video codec Bit rate
AAC, COOK RV30, RV40 40 Mbps
Amplier
• FTC total output power: 42 W
• Speaker: 13 W (1% THD, 4 ohm, 300
Hz - 9 kHz)
• Subwoofer: 16 W (1% THD, 4 ohm, 30
Hz - 100 Hz)
• Total output power: 80 W RMS (10% THD)
• Frequency response: 20 Hz-20 kHz / ±3 dB
• Signal-to-noise ratio: > 65 dB (CCIR) /
(A-weighted)
• Input sensitivity:
• AUX: 2 V rms
• AUDIO IN: 1 V rms
Video
• Signal system: PAL / NTSC
• HDMI output: 480i/576i, 480p/576p, 720p,
1080i, 1080p, 1080p24
Audio
• S/PDIF Digital audio input:
• Coaxial: IEC 60958-3
• Optical: TOSLINK
• Sampling frequency:
• MP3: 32 kHz, 44.1 kHz, 48 kHz
• WMA: 44.1 kHz, 48 kHz
• Constant bit rate:
• MP3: 32 kbps - 320 kbps
• WMA: 48 kbps - 192 kbps
Radio
• Tuning range:
• Europe/Russia/China: FM 87.5-108
MHz (50 kHz)
• Asia Pacic/Latin America: FM 87.5-108
MHz (50/100 kHz)
• Signal-to-noise ratio: FM 50 dB
• Frequency response: FM 180 Hz-12.5 kHz
/ ±3 dB
