The following tables will illustrate the different combinations of Dolby Pro
Logic II, Dolby Digital, DTS and Dolby Headphone and the resulting
indication in the display of the base station depending on the nature of the
digital audio input signal (i.e. stereo or multichannel).
For example:
– when Dolby Pro Logic II is on (in Music or Movie mode) Dolby Headphone will
automatically be activated: all green virtual multi-channel indicators
(, , ,,) will light up;
– when Dolby Pro Logic II is off but Dolby Headphone is still activated,
the green indicator lights up, indicating Dolby Headphone stereo sound
reproduction;
– when Dolby Headphone is bypassed (resulting in Dolby Pro Logic II
automatically being bypassed too), the green stereo indicator lights up,
indicating normal stereo sound reproduction.
For example:
– when Dolby Digital is on then Dolby Headphone will automatically be
activated: all green virtual multi-channel indicators ( , , , , ) will
light up;
– switching off Dolby Headphone in case of a Dolby Digital multichannel signal
is not possible.
– similar for DTS multichannel signals.
