CASSETTE RECORDER
21
English
AZ 2536/01 page 21
Cassette playback
1 Select TAPE source.
™ Display: shows throughout tape operation.
2 Press STOP
•
OPEN 9 / to open the cassette door.
3 Insert a recorded cassette and close the cassette door.
4 Press PLAY 1 to start playback.
5 To interrupt playback press PAUSE ;. To resume, press this key
again.
6 By pressing SEARCH 5 or 6 on the set fast winding of the tape is possible in both directions.
7 To stop the tape, press STOP
•
OPEN 9 /.
• The keys are automatically released at the end of a tape, except if PAUSE ; has been activated.
General information on cassette recording
• Recording is permissible insofar as copyright or other rights of third parties are not infringed.
• This deck is not suitable for recording on CHROME (IEC II) or METAL (IEC IV) type cassettes. For
recording you should use NORMAL type cassettes (IEC I) on which the tabs have not been
broken.
• Check and tighten slack tape before use with a pencil, to avoid jamming the deck machanism.
• The recording level is set automatically. Altering the VOLUME MAX SOUND or BASS, MID &
HIGH controls will not affect the recording in progress.
Helpful hints:
-No recording will take place during the 7 seconds in the beginning of the tape.
•To prevent the accidental erasure of a recording, keep the
cassette side to be safeguarded in front of you and break out
the left tab. Recording on this side is no longer possible.
CASSETTE RECORDING
CASSETTE PLAYBACK
1
AZ2536_01 eng 4/7/2004 05:51 PM Page 21
