Feature Highlights
9 10
LIGHTING CONTROL/TURN SIGNAL LEVER
Pull
to Flash
High Beams
Push for
High Beams
:Turnstail,parking,dashboard,
andheadlightson.
AUTO:Thelight
sensorautomatically
determineswhentoturn
theheadlightsonoroff.
:Turnsfoglights
ononlywhenheadlights
areon.
:Turnstail,parking,
anddashboardlightson.
WINDSHIELD WIPER/WASHER CONTROL LEVER
Rear Window
Wiper/Washer
INT =Intermittent
ON =Normalspeed
=Rearwasher/wiper
(holdasdesired)
AUTO:Therainsensorsensestheamountofrainfallandturnsthewipers
onoroff.Rotateinnerringawayfromyou(clockwise)forlesssensitivity
(requiresmoreraintoturnwiperson)andtowardsyou(counterclockwise)
formoresensitivity(requireslessraintoturnwiperson).
N O T E :
VehiclesnotequippedwithAUTOwiperswillhaveINTwipers.Setthelever
toINTandchooseanintervaltimingbyrotatingtheringbetweenfastandslow.
AUTO
(auto wipers)
OFF
MIST
(single wipe)
LO
(low
speed wipers)
HI
(high
speed wipers)
Pull lever
to dispense
windshield
washer fluid.
More sensitive
Less sensitive
