Lowrance - LVR-880 Operation Instructions 39
Select the desired setting then press ENT.2.
CHECK SUM ON (on) is the usual setting. The COM PORT uses 4800 baud rate and can
receive the following GPS data sentences: RMC, GGA, GLL, GNS. Additionally, the radio
will output the following NMEA DSC data: DSC (for DSC call), DSE (for enhanced position).
4-10 Select the GPS Source (GPS SOURCE)
This radio can use either NMEA0183 or NMEA2000 protocol to receive GPS data from a
compatible GPS unit.
Note: NMEA2000 SOURCE options will appear (up to 4 sources showing the actual source
name) only if NMEA2000 is operational.
RADIO SETUP
INT SPEAKER
COM PORT
GPS SOURCE
GPS SOURCE
NMEA0183
LGC3000
LCX113CHD
Select 1. RADIO SETUP then GPS SOURCE. (If there is only one NMEA protocol available on
your vessel, only that will be shown.)
Select 2. the desired NMEA source then press ENT.
4-11 Select the FM Region (FM REGION)
RADIO SETUP
COM PORT
GPS SOURCE
FM REGION
FM REGION
USA
EUROPE
AUS/NZ
FM REGION
AUS/NZ
JAPAN
OTHERS
Selec1. t RADIO SETUP then FM REGION.
Select the FM region and press ENT. If you selected USA, EUROPE, AUS/NZ, or JAPAN, the 2.
FM REGION selection is now complete.
If you selected OTHERS, you must also specify the channel spacing, upper frequency,
and lower frequency.
FM REGION
AUS/NZ
JAPAN
OTHERS
OTHERS
CH SPACING
UPPER FREQ
LOWER FREQ
CH SPACING
200KHz
100KHz
50KHz
Select C1. H SPACING then select the channel spacing.
Select UPPER FREQ then select the upper frequency (between 108.00 and 106.00 MHz). 2.
Select LOWER FREQ then select the lower frequency (between 87.50 and 89.50 MHz).3.
