Use To
3 Fax
Access the fax menu and send faxes.
4 Memory Device
or
PictBridge
View, select, print, or attach photos and documents to e‑mail.
Note: This icon appears only when you return to the home screen while a
memory card, flash drive or PictBridge‑enabled camera is connected to the
printer.
5 SmartSolutions
Access the SmartSolutions menu.
6 Ink levels icon
• View the current ink levels of the installed cartridges.
• Access cartridge maintenance and information functions.
7 Setup icon
Access the setup menu and change printer settings.
8 Eco‑Mode icon
Activate Eco‑Mode to select the following options:
• Change to Sleep mode after the printer is left idle for 10 minutes.
• Set screen brightness to low.
9 Wi‑Fi indicator
or
Ethernet indicator
Check the network connection status of your printer and access the network
settings.
Navigating menus using the touch screen
Paper Size
PaperType
Photo Size
Change Print Settings
Change Print Settings
Letter
Auto Detect
4x6 in.
Select Photos
Layout
1 - 6 of 10
12
3
5
6
4
Use To
1 Left arrow
Scroll left.
2 Right arrow
Scroll right.
3 Accept
Save your setting.
4 Up arrow
Scroll up.
5 Scroll bar
Scroll up and down the menu list.
6 Down arrow
Scroll down.
About your printer 14
