2-94 Service Manual
5016-001
White Spots Service Check
FRU Action
1 Paper Check paper for moisture resulting from high
humidity.
2 Image Transfer
Roller
High Voltage
Power Supply
(HV1)
Fuser Frame
Resistor Board
(PWB-R1)
Printer Main
Engine Board
(PWB-A)
The printer may produce poor image transfer.
Replace the listed parts in the following order:
1. Image transfer roller
2. High voltage power supply
3. Fuser frame resistor board
4. Printer main engine board
