5.13 Base Enclosure
1. Prepare the computer for disassembly (Section 5.3)
and remove the following components:
a. Hard drive (Section 5.4)
b. Optical drive (Section 5.6)
c. Memory module compartment cover (Section 5.7)
d. Mini PCI compartment cover (Section 5.8)
e. Keyboard cover (Section 5.9)
f. LED board (Section 5.10)
g. Keyboard (Section 5.11)
h. Display assembly (Section 5.12)
2. Position the computer with the front panel toward you.
Base Enclosure Spare Part Number Information
For use on HP Pavilion ze2300 models
For use on Compaq Presario M2300 models
395141-001
395142-001
