NOTE:
Memory configurations listed do not apply to "Factory Integrated Models".
HP ProLiant DL370 G6 Models
HP ProLiant ML370 G6 Models
DDR3 memory population guidelines
For detailed memory configuration rules and guidelines, please use the Online DDR3 Memory Configuration Tool:
www.hp.com/go/ddr3memory-configurator
Some DIMM installation guidelines are summarized below:
For servers with eighteen (18) memory slots:
There are three (3) channels per processor; six (6) channels per server
There are three (3) DIMM slots for each memory channel; eighteen (18) total slots
Memory channel 1 consists of the three (3) DIMMs that are closest to the processor
Memory channel 3 consists of the three (3) DIMMs that are furthest from the processor
DIMM slots that are white should be populated first
Do not mix Unbuffered memory (UDIMMs) with Registered memory (RDIMMs)
Do not install DIMMs if the corresponding processor is not installed
If only one processor is installed in a 2CPU system, only half of the DIMM slots are available
To maximize performance, balance the total memory capacity between all installed processors
It is not required, but it is recommended to load the channels similarly if possible
If any Quad rank DIMMs are installed, all channels are limited to only 2 DIMMs per channel.
You can only install two quad-rank DIMMs per channel
You can only install two UDIMMs per channel; if available, the third slot in the channel must remain empty
Populate DIMMs from heaviest load (quad-rank) to lightest load (single-rank) within a channel
Heaviest load (DIMM with most ranks) within a channel goes furthest from the chipset
For memory mirroring mode, channel 3 must be unpopulated. Channels 1 and 2 are populated identically
For lock-step mode, channel 3 must be unpopulated. DIMMs in channels 1 and 2 will be installed in pairs. The paired
slots will be 1,4; 2,5; 3;6 on a 3DPC system or 1,4; 2,5; on a 2DPC system
DIMM slot/capacity/populated speed table
DIMM Type
Registered DIMMS
(RDIMMs)
Unbuffered with ECC
DIMMs (UDIMMs)
DIMM Rank
Dual Rank (2R)
Quad Rank (4R)
Single
Rank (1R)
Dual Rank
(2R)
DIMM Capacity
2GB 4GB 8GB 8GB 4GB
16GB
1GB 2GB
DIMM Native Speed
(MHz)
1333 1333 1066 1333 1066 1066 1333 1333
SLOTS THAT CAN BE POPULATED
18 slot servers
18 18 18 18 12 12 12 12
MAXIMUM CAPACITY (GB)
36 72 144 144 48 192 12 24
POPULATED DIMM SPEED (MHz)
1 DIMM Per
Channel
1333 1333 1066 1333 1066 1066 1333 1333
2 DIMM Per
Channel
1333
*
1333
*
1066 1333
*
800 800 1066 1066
3 DIMM Per
Channel
800 800 800 800
n/a n/a n/a n/a
* Supported with ROM update via ROM Based Setup Utility (RBSU)
NOTES:
PC3-10600 DIMMs have a maximum speed of 1333MHz. PC3-8500 DIMMs have a maximum speed of 1066MHz
