7 Power management
Inserting or removing the battery
NOTE: For additional information on using the battery, refer to Using battery power on page 45.
Inserting the battery
1. Turn the computer upside down on a flat surface, with the battery bay toward you.
2. Align the battery (1) with the outer edge of the battery bay, and then rotate the battery into the
battery bay (2) until it is firmly seated.
The battery release latch automatically locks the battery into place.
Inserting or removing the battery 39
