If your vehicle is equipped with
the optional heavy duty trailer tow
wiring, it is pre-wired for trailer
towing. An electrical connector is
provided under the instrument
panel for installing a
customer-supplied electric brake
controller. Another electrical
connector is provided at the hitch.
This connector provides power to
the trailer for taillamps, stop and
turn lamps, back up lamps, battery
charge, electric brakes (when a
customer provided controller is
installed) and ground. The kit
included with your vehicle
provides you with adaptors to
attach the brake controller and
convert the hitch connector for
Class I trailer usage.
Trailer towing table (with heavy
duty trailer tow option)
GCWR (Gross Combined Weight
Rating)/trailer weights
Engine
Rear
axle
ratio
Tire size
Maximum
GCWR
Trailer weight
range
(0 - maximum)
4x2
4.6L 3.31
40.6 cm
(16 in)
4 990 kg
(11 000 lbs.)
0-2676 kg
(0-5 900 lbs.)
5.4L 3.31
40.6 cm
(16 in)
5 443 kg
(12 000 lbs.)
0-3 039 kg
(0-6 700 lbs.)
5.4L 3.73
40.6 cm
(16 in)
6 123 kg
(13 500 lbs.)
0-3 628 kg
(0-8 000 lbs.)
Driving
119
