4.4.93. Map Descriptor Example 89 - edit read aux.
// Client Side Mao Descriptors
Map Descriptor
Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function,
Node_Name, SysPlus_Cmd, Store_Data_Array_Name, Store_Data_Array_Offset, Length
Ed_Rd_Aux, Rd_Triggers, 5, art, SYSPLUS_01, Ed_Rd_Aux, Ed_Rd_Aux, 0, 1
This command is triggered by writing any value to Data_Array_Name at Data_Array_Offset.
The retrieved data is stored as follows:
Offset from Store_Data_Array_Offset
Description
0
Aux0 status
..
..
9
Aux9 status
4.4.94. Map Descriptor Example 90 - edit read cycles
// Client Side Mao Descriptors
Map Descriptor
Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Store_Data_Array_Name, Store_Data_Array_Offset, Length
Ed_Rd_Cycles, Rd_Triggers, 6, art, SYSPLUS_01, Ed_Rd_Cycles, Ed_Rd_Cycles, 0, 1
This command is triggered by writing any value to Data_Array_Name at Data_Array_Offset.
The retrieved data is stored as follows:
Offset from Store_Data_Array_Offset
Description
0
Number of cycles
