9
1.) Elapsed Time (Minutes) Display.
2.) Volume level (00-32) and Track Number Display.
3.) VOL (Volume) Indicator – Appears when adjusting Volume level.
4.) PROG (Program) Indicator – Appears when programming tracks or
playing programmed tracks.
5.) RAND (Random) Indicator – Appears when Random playback mode
is selected.
6.) INTRO Indicator – Appears when Intro playback mode is selected.
7.) ANTI-SHOCK Indicator – Indicates Anti-Shock Protection is activated.
8.) Anti-Shock Status Bar.
9.) Elapsed Time (Seconds) Display.
10.) Battery Status Indicator – Appears when battery level becomes low.
11.) REPEAT 1 /ALL Indicators – Appears when the Repeat playback mode
is selected.
LCD DISPLAY INDICATORS
1
2
4 5
6
7
8
10
11
9
LCD Display
3
