4
Table of Contents
Trademarks
Each name of corporations or products in this book is either a registered trademark or a trademark of its respective
corporation.
Features and Design . . . . . . . . . . . . . . . . . . .3
Table of Contents . .
. . . . . . . . . . . . . . . . . . . .4
To the Owner. .
. . . . . . . . . . . . . . . . . . . . . . . .5
Safety Instructions . .
. . . . . . . . . . . . . . . . . . .6
Air Circulation 7
Moving the Projector 7
Installing the Projector in Proper Directions 8
Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Part Names and Functions . .
. . . . . . . . . . .10
Front 10
Back 10
Bottom 10
Rear Terminal 11
Top Control 12
Remote Control 13
Laser Pointer Function 14
Pointer Function 14
Wireless Mouse Operation 15
Remote Control Code 15
Remote Control Battery Installation 16
Remote Control Operating Range 16
Adjustable Feet 16
Installation. . . . . . . . . . . . . . . . . . . . . . . . . . .17
Positioning the Projector 17
Connecting the AC Power Cord 18
Connecting to a Computer 19
Connecting to Video Equipment 20
Connecting to Component Video Equipment 21
Basic Operation . . . . . . . . . . . . . . . . . . . . . .22
Turning On the Projector 22
Turning Off the Projector 23
How to Operate the On-Screen Menu 24
Menu Bar 25
Zoom and Focus Adjustment 26
Auto Setup Function 26
Keystone Correction 26
Sound Adjustment 27
Remote Control Operation 28
Computer Input . . . . . . . . . . . . . . . . . . . . .30
Input Source Selection
(RGB: Computer 1 (Analog)/Computer 2 ) 30
Input Source Selection
(RGB(PC digital), RGB(AV HDCP))
31
Computer System Selection 32
Auto PC Adjustment 33
Manual PC Adjustment 34
Image Mode Selection 36
Image Adjustment 37
Screen Size Adjustment 38
Video Input . . . . . . . . . . . . . . . . . . . . . . . . . .40
Input Source Selection (Video, S-video) 40
Input Source Selection
(Component, RGB Scart 21-pin) 41
V
ideo System Selection 42
Image Mode Selection 43
Image Adjustment 44
Screen Size Adjustment 46
Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47
Setting 47
Maintenance and Cleaning . . . . . . . . . . . . .58
Warning Indicator 58
Cleaning the Filter 59
Resetting the Filter Counter 59
Slide Shutter 60
Cleaning the Projection Lens 60
Cleaning the Projector Cabinet
60
Lamp Replacement 61
Resetting the Lamp Counter 62
Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . .63
Troubleshooting 63
Menu Tree 67
Indicators and Projector Condition 69
Compatible Computer Specifications 70
Technical Specifications 72
Optional Parts 73
PJ Link Notice 74
Configurations of Terminals 75
PIN Code Number Memo 76
Dimensions 77
